Features
◆ Adopting thermal imaging technology, imaging clearly, can search in large area and recognize objectives in long distance
◆ 640×512 high resolution infrared detector with NETD≤ 50mK
◆ Day and night 2 megapixels low illuminance color camera, realizing day and night continuous monitoring
◆ Optional auto focusing function, realizing multiple focusing mode and triggering mode
◆ Optional thermal imaging camera presetting function, remembering FOV of each preset bit, enhancing working efficiency
◆ 3D locating function, can realize frame selection magnifying function and clicking to center function, reducing operating difficulty, enhancing device usability
◆ High reliability aluminum alloy electro-optical pantilt, reinforcement design, strong ability of anti-wind, anti-salt fog, low and high temperature resistance etc
Specification
| Monitoring distance | Visible camera | 2000m |
| Object | Human | Vehicle |
| Thermal camera | 5950m | 17000m |
| 1980m | 4250m |
| 990m | 2130m |
| Thermal detector | Detector | Uncooled microbolometer focal plane array(Vox) |
| Effective pixel | 640×512 |
| Spectral range | 8~ 14μm |
| NETD | ≤50mK@F1.0,300K |
| Frame rate | 25Hz |
| Image process | DDE, pseudo color |
| Thermal lens | Focal length | 30~150mm,5x zoom |
| FOV | 2.9°×2.3°~14.6°×11.7° |
| F value | F1.0~ F1.2 |
| Lens control | E-zoom, e-focus, auto focus |
| IFOV | 0.08~0.40mrad |
| HD Camera | Sensor type | 1/1.8’’ Progressive Scan CMOS |
| Coding format | H.264/MJPEG/MPEG4 |
| Video resolution | 1080P, CIF,supporting three stream |
| Video bit rate | 32Kbps~ 16Mbps |
| Video frame rate | 1~ 25F/S (50Hz), 1~ 30F/S (60Hz) |
| HD lens | Focal length | 10~320mm |
| FOV | 1.4°~ 38.5° |
| Other | Defog, Auto focus Support for optional |
| Pan-tilt | load | 25kg |
| Angle | Pan: 0°~ 360°; Tilt: -45°~ +45° |
| speed | Pan: 0.01°~ 45°/s; Tilt: 0.01°~ 30°/s |
| Preset | 200 |
| Preset accuracy | ±0.1°(±0.05° optional) |
| Auto cruise | 8 paths, 10 presets each path |
| Auto scan | 1 path |
| Anti-wind | Grade 12 |
| Interface | Power supply | DC30V |
| Network interface | 1x10Base-T/100Base-TX, RJ45 |
| Video interface | RS485/RS422, BNC video output |
| Environment indicators | temp. | operation -25℃~ +55℃ (-40℃~ +65℃ optional), Storage -40℃~ +65℃ |
| Protection grade | IP66 |
| Power supply | power supply | Wide range power input AC90~305V to output DC30V/10A, anti-water power supply |
| Consumption | ≤180W |
